The Enjoybot Lithium Battery supports flexible scaling configurations.
Use this cable with solar energy systems, golf carts, and any other applications where you need a lot of power at one time.
Chain units in series 24V, 36V or 48V output for high-voltage demands such as off-grid solar inverters requiring 48V DC input.
Critical Rule: Ensure all batteries share identical State of Charge (SOC) (≤5% variance) to prevent voltage imbalance risks.
Combine batteries in parallel to achieve 200Ah, 300Ah, or 400Ah capacity setups tailored for prolonged high-current applications like industrial golf carts or backup power systems.
For example, build a 48V 400Ah system by first creating two 24V 200Ah clusters (parallel), then connecting them in series.
*The number of series and parallel connections for the battery is limited. Refer to the product page for specific information.
Specification:
| Wire Gauge | 3 AWG |
| Length | 13.7 inches (350mm) |
| Recommend Battery | 12 volt 100ah/24V/36V/48V |
| Recommend Max Inverter Load | 1000 watt |
| Recommend Max Current | 100A |
| Terminal Type/Size | M8 |
| Warranty | 1 year |
| Certification | UL, ROHS |
| Compatible Connection | Series, Parallel |
